FEATURES
Delivers up to 1898Nm maximum torque
Magnesium alloy front housing and back head cover
Durable composite body construction
Lightweight design improves operator handling
Suitable for heavy-duty automotive and industrial applications
Specifications
Drive
3/4"
Torque Range
200-1,100 ft-lb/271-1,491 Nm
Max Torque
1,400 ft-lb/1,898 Nm
Free Speed
8,500 RPM
Average Air Consumption
4.8 CFM/136 L/min
Air Pressure
90 PSI/6.3 bar
Overall Length
7-13/16"/198 mm
Net Weight
1.90 kg
Net Weight
4.20 lb
Air Hose
3/8"
Sound Pressure
85.0 dBA
Vibration Level
4.7 m/s²
Bolt Capacity
1"/25 mm
Air Inlet
1/4"
